AIM of the project:

To provide the households of the villages of Gokuldem and Shirlim with:

• Adequate number of Bio-Toilets: Individual as well as Community Bio-Toilets (To put an end to Open Defecation).
• Adequate drinking water supply.

OVERALL OBJECTIVE:

To contribute in providing support to village infrastructure development (water & Sanitation ) to Gokuldem & Shirlim village of Quepem Taluka and improve livelihoods of community.

• Repair and reconstruct RCC reservoir tanks located uphill in both villages.
• Clean up wells and created alternate channel of water for both villages.
• Install Community bio toilet complexes ( Gavaliwada , Vaghulwada)
• Install Toilet+ Urinal complex for GPS Shirlim & Anganwadi Gokuldem
• Install  Individual household bio toilets in Gokuldem & Shirlim

Changed pipeline form uphill water source till village.

ACTIVITIES & PROGRAM REACH

• In both the villages, villagers were dependent on uphill spring water, wells & after February on PWD tanker water supply, also villages were having two unused abandoned wells as alternate source.

Sustainable Water Solution:

•  The existing water reservoirs at both villages are repaired and their water storage capacity is increased.
• The pipe lines from uphill reservoirs were changed and water coming through is stored in 5000 litres tank.
• The existing common single taps converted in multi-tapped 2000 & 3000 litres LLDPE tanks. Total such 15 LLDPE tanks are installed in both villages.
• Both wells cleaned and brought into usage for drinking purpose and as alternate water supply channel the system made to store well water in both 5000 litres tanks and all common tanks are connected to existing water system, ending the dependency on tanker for water supply permanently.

Bio- Toilets:

• 2 Community Bio-toilet duel units installed for Gavaliwda community (male-female separate, 6 houses 53 population) ending open defecation in Gavaliwada area.
• 1 Community bio-toilet duel unit installed for Vaghulwada area (6 houses 37 population) ending open defecation from the area totally.
• 53 individual household bio-toilet units in Shirlim installed are used by 58 households and 406 population total.
• 49 individual household bio toilets installed in Gokuldem are used by 55 households and 413 population total.
• Anganwadi Urinal-toilet installed is used by 21 children in Gokuldem.
• GPS Shirlim Urinal-toilet installed is used by 11 Anganwadi children and 23 GPS students.

b. Water & Sanitation Support 2016-2017 (Pokharmol & Nunem)

OVERALL OBJECTIVE:

To contribute in providing support to village infrastructure development (water & Sanitation ) to Pokermol & Nunem village of Sanguem taluka and improve livelihoods of community.

• Tapping uphill springs in Nunem, constructing RCC water tank uphill and supply water throughout village.

• Cleaning up wells and increase storage capacity plus bring into use unused well for drinking water as well as water for domestic usage.
• Installation of Duel Power Solar pump on both wells in Pokermol and supply water throughout village.
• Installation of individual Bio toilets (Pokermol, Vagregal) & Community Bio toilet in Pokermol.

In both the villages villagers were dependent on uphill spring water (Nunem) and only on wells (Pokharmol) & after February on PWD tanker water supply, also Pokermol village having two unused abandoned wells as alternate source.

  Sustainable water solution

Nunem:

Uphill water sources tapped (3) into one RCC reservoir giving total storage of 25000 liters. The pipe lines from uphill reservoir connected to the other storage tank in village collecting 35000 litres water. The existing common single taps converted in multi-tapped 1000 liters tanks. Total 10 water stations constructed giving benefit to 114 houses.

Pokermol:

Both wells cleaned and brought into usage of drinking purpose as well as for domestic usage. Duel power solar pump fitted on both wells. Water pumped into both 5000 Litres tanks and supplied to village.

Bio-Toilets

44 Individual household bio toilets installed at Pokermol village.

7 Individual household bio toilets installed at Vagregal village for 7 houses.

1 Community bio-toilet duel unit installed in Pokermol near club house (6 houses benefiting 37 individuals ending open defecation from the area totally.

c. Sanitation Support 2017-2018  (Kalay, Netravali, Sanguem Taluka)

The sanitation support for the FY 2017-2018 was given to Kalay, Netravali -Sanguem Taluka in collaboration with Colorcon Asia Pvt. Ltd.   A total

During routine visits of our project staff and surveys carried out, it was noted that Mangal, Nunem, Talsai villages from Netravali Village Panchayat areas, and Devnamol, Muslimwada and Voldev villages from Kalay Panchayat areas have sanitation problems, as there are either no toilets in the villages or some of the toilets provided by government are either broken or not in an usable condition.

After combining all the six villages there are around 309 households out of which 218 don’t have toilet facility. Villagers have to go in the open to defecate which in turn leads to several health problems. Lack of proper sanitation facilities impacts the health, and environment. With open defecation ground water gets contaminated that is used for drinking and cleaning purposes resulting in water borne diseases. Basic health is determined by the number of factors such as personal hygiene, clean environment, safe and clean drinking water, nutritional intake and healthcare facilities. Based on our previous experiences, toilets are also a boon for women who otherwise have to go out in the open, and are shy to do so, or face risk of going out in the open at night.

Project Objectives:

To contribute in providing support to village & infrastructure development (Sanitation issues) to Mangal, Nunem, Talsai, Devnamol, Muslimwada, & Voldev villages of Sanguem Taluka and improve livelihood of community.

Impact of the Project on the Lives of the Beneficiaries/Community/Target Group.

• Open defecation free villages & increase in overall personal hygiene plus village cleanliness.
• Improvements in overall personal hygiene and decrease in waterborne diseases.
• Impact on environment.
• No contamination of underground water bodies.
• Safety for women and girls and for villagers from going out in the open/fields/ jungles when it is dark.

Table of Bio- Toilet installed in Kalay- Netravali, Sanguem Taluka
